A single strand slab caster at steel melt shop casts stainless steel slabs. Liquid steel is produced through electric arc furnace (EAF)-AOD Convertor-ladle refining furnace route.
Odisha
| Product | Width | Thickness | ||
|---|---|---|---|---|
| Min | Max | Min | Max | |
| Slab | 1000 | 1650 | 160 | 220 |
HR Black : As cast/ ground stainless steel slabs are first heated and soaked in reheating furnace, they are rolled to intermediate thickness in the roughing mill, and then to the final thickness in the tandem mill. Hot Strip Mill is also equipped with online surface inspection machine for detection of surface flaws during hot rolling of strips.
Hot rolled stainless steel coils are annealed and pickled in continuous annealing-pickling lines having scale breaker, shot blasting unit, sulphuric acid, and mixed acid bath. HRAP coils have a cleaner surface and have improved mechanical properties for downstream processing. HRAP line is also equipped with online reduction for providing product in 2E finish.
Odisha
| Product | Max Width | Thickness | ||
|---|---|---|---|---|
| Min | Max | Min | Max | |
| Hot Rolled Coil | 1000 | 1650 | 2.0 * | 10 |
| N1 | 1000 | 1650 | 2.0 * | 10 |
| 2E | 1000 | 1600 | 1.4 * | 6.7 |
Our stainless steel cold rolling facility is equipped with all state-of-art facilities like 20-Hi-Sendzimier Cold Rolling Mill with IMR Shifting, Mill Tilting and Shape meter advantages for higher degree of shape & profile correction. The CR Annealing & Pickling line is on environment friendly LPG fuel with better temperature control, associated with Electrolytic and Acid Pickling with very high control on pickling process. The online Skin Pass and Tension Leveling has made this line capable of producing finished 2B/2D stainless steel products at par with international quality. The on-line automatic surface inspection system also provides a very high resolution surface quality. The Skin Pass Mills help cater to high luster requirements. Other facilities include Bright Annealing units and Strip Grinding line to produce desired surface finishes of stainless steel products.
Odisha
| Product | Width | Thickness | ||
|---|---|---|---|---|
| Min | Max | Min | Max | |
| CRAP | 1000 | 1600 | 0.3 * | 5.0 |
No 1 finish plates in stainless steel are produced after annealing and pickling, or by cutting hot rolled annealed pickled coils to desired lengths.
Odisha
| Product | Width | Thickness | ||
|---|---|---|---|---|
| Min | Max | Min | Max | |
| Plates | 1000 | 1620 | 11 | 80 |
The following data sheets can be used as a reference for a better understanding of different stainless steel grades and product information:
200 series of Stainless Steel products
300 series of Stainless Steel products
400 series of Stainless Steel products
Duplex grade of Stainless Steel
Jindal Stainless is a name synonymous with unparalleled quality assurance for stainless steel flat products across all grades. Take a look at our various stainless steel grades, sizes, and finishes.
Quality Management System (ISO 9001:2015) Certificate
Environment Management System (ISO 14001:2015) Certificate
Occupational Health & Safety Management System (as per ISO 45001:2018) Certificate
Energy Management System (as per ISO 50001:2018) Certificate
Certificate of Conformity of Factory Production Control 0045-CPR-1752 CE – Mark Certificate
Certificate as per Pressure Equipment Directive 2014/68/EU: EN 764-5, AD 2000-Merkblatt
Materials approval certificate for the classification of Marine Units
Approval of Manufacturer certificate as per DNV GL rules for classification - Ships
The R&D division plays a pivotal role in retaining the position of Jindal Stainless as India's largest stainless steel manufacturing company. This is achieved through continuous upgradation of quality, processes, services, and product innovation to develop new stainless steel products at competitive costs. Cross-fertilization of knowledge between production, quality control, and commercial units, in order to maintain global standards, has been the guiding principle of the R&D function at Jindal Stainless.
In addition to the above, the R&D division closely interacts with reputed national and international laboratories, scientific institutions, and universities to avail expert services and knowledge for critical investigations.
